Models | Processing OD/inch | Processing T: m/m | Speed sec/p |
Die Length 4pcsxm/m |
Horse Power H.P. |
Processing Bed Area LxWxH m/m |
Weight |
380F | 1/2"~11/2" | 0.6~1.4 | 8~15 | 300 | 12 1/4 | 1750X1600X1600 | 3.2 |
500F | 5/8"~2" | 0.6~1.6 | 8~25 | 300 | 17 1/4 | 1850X1700X1600 | 4.2 |
500FA | 5/8"~2" | 0.8~1.6 | 25~60 | 700 | 23 1/4 | 2000X1700X1600 | 5.2 |
800F | 1"~3" | 1.0~3.0 | 25~60 | 300 | 30 1/4 | 1900X1850X1700 | 6 |
1000F | 1 1/2"~4" | 1.0~3.0 | 35~80 | 350 | 30 1/4 | 2000X2000X1750 | 7 |
1000FA | 1 1/2"~4" | 1.2~3.6 | 40~100 | 700 | 35 1/4 | 2200X2000X1750 | 8 |
1500F | 3"~6" | 1.2~3.6 | 40~100 | 400 | 35 1/4 | 2000X2200X1800 | 8.8 |
Machine Features: | Raw Materials: |
1.Easy to operate. 2.Easy to maintin. 3.Wide working range. 4.Handles 6M or set-length tube processing. 5.Requires no special location. 6.Automatic malfunction display. 7.Excellent construction design. 8.Canbe designed according to cutstomers' reqirements. |
1.Steel tubes 2.Stainless steel pipes 3.Brass pipes 4.Aluminum pipes |
Standard Accessories | |
1.Machines 2.Control box 3.One set of dies |
|
Typical Applications: | Optional Accessories: |
1.Staircases, balconies, railing 2.Door and windows handles. 3.Furniture items, tables, chairs,and beds 4.Lighting and candelabra central stems. 5.Bicycle parts, front forks, central drums 6.Auto rearview-mirror central stems 7.Fishing rod grips 8.Decorations |
1.PLC 2.Semiautomatic supply equipment 3.Fully automatic supply equipment 4.6M shaft |
