LIGHTWEIGHT
C-SHAPE STEEL FORMING MACHINE
Size: 75X35~250X75
|
|
C&Z-SHAPE
STEEL
|
||||||
|
W
|
H1
|
H2
|
B
|
t(mm)
|
 |
 |
|
75
|
45
|
47
|
15
|
1.6~2.5
|
||
|
100
|
50
|
52
|
15
|
1.6~2.5
|
||
|
125
|
50
|
52
|
15
|
2.5~3.2
|
||
|
150
|
65
|
67
|
18
|
2.5~3.2
|
||
|
200
|
75
|
77
|
20
|
2.5~3.2
|
||
|
250
|
75
|
77
|
20
|
3~4
|
||
|
SAFETY FENCE
|
||
 |
 |
- VEHICLES WILL NOT FLING OUT |
| - VEHICLES WILL BE REDIRECTED PPRALLEL TO THE ROAD | ||
| - IT PREVENTS STRONG SHAKING AND REDUCES ACCIDENTS | ||
| Specification: | |
| 1. Hydraulic Motor : 25 Hp | |
| 2. Number Of Stands : 12 Set | |
| 3. Roll Shaft DIA : 65 mm | |
| 4. Thickness : 1.0 ~ 4.0 mm | |
| 5. Forming Speed : 12-15 M/min | |
| 6. Standard Fitttingst | |
| Uncoiler , Hydraulic Cuttting Device , Stuff Withdraw Rack | |
| Raw Material | -> | Welding table | -> | Roll Forming | -> | Main Machine | Contorller | -> | Cumulate Area |
| Uncoiler | Roll Former | Cutting-Off | Run Out Table | ||||||
|
<-------------------------------------
Length=20 M (KC-G430A) --------------------->
|
|||||||||
 |
|||||||||
